1756-CNBD
delivery time：in stock
Technical Specifications
Electrical
With optical interface
No
Supporting protocol for TCP/IP
No
Supporting protocol for DeviceNet
No
Supporting protocol for other bus systems
Yes
Redundancy
No
IO link master
No
Supporting protocol for DeviceNet Safety
No
Supporting protocol for EtherNet/IP
No
Transmission rate
5000 kBps
Power dissipation
5.1 W
Thermal dissipation
17.4 BTU/h
ControlNet port
1 ControlNet BNC
Enclosure type rating
None (open-style)
Number of nodes, max
99 nodes
Current draw
970 mA @ 5.1V DC, 1.7 mA @ 24V DC
ControlNet cable
1786-RG6 quad shield RG6 coaxial cable
Wiring category
1 - on ControlNet ports, 3 - on NAP ports
Connections supported, max
64 maximum
Isolation voltage
Standard: 30V (continuous), basic insulation type, ControlNet network to, backplane, Redundant: 30V (continuous), basic insulation type, ControlNet A/B to, backplane, and ControlNet A to ControlNet B, USB to backplane and USB to ControlNet, No isolation b
Supporting protocol for LON
No
Supporting protocol for ASI
No
Supporting protocol for PROFIBUS
No
Supporting protocol for CAN
No
Supporting protocol for INTERBUS
No
Supporting protocol for KNX
No
Supporting protocol for Modbus
No
Supporting protocol for Data-Highway
No
Supporting protocol for SUCONET
No
With potential separation
No
Supporting protocol for SERCOS
No
Supporting protocol for INTERBUS-Safety
No
Radio standard Bluetooth
No
Radio standard Wi-Fi 802.11
No
Supporting protocol for AS-Interface Safety at Work
No
Supporting protocol for Foundation Fieldbus
No
Supporting protocol for PROFINET CBA
No
Supporting protocol for PROFINET IO
No
Supporting protocol for PROFIsafe
No
Supporting protocol for SafetyBUS p
No
Radio standard GPRS
No
Radio standard GSM
No
Radio standard UMTS
No
Slot width
1
Logix communication connections range
40...48
NAP cable
1786-CP
NAP port
1 NAP RJ45
Environmental
Surrounding air temperature, max
60 °C
Storage temperature
-40 to 85 °C
Emissions
CISPR 11: Class A
Vibration
2 G @ 10...500 Hz
ESD immunity
6 kV contact discharges, 8 kV air discharges
EFT/B immunity
±3 kV at 5 kHz on ControlNet ports
Relative humidity
5...95% noncondensing
Shock
Operating: 30 G, Non operating: 50 G
Conducted RF immunity
10V rms with 1 kHz sine-wave 80% AM from 150 kHz...80 MHz
Surge transient immunity
±2 kV line-earth (CM) on ControlNet ports
Operating temperature
0 to 60 °C
Radiated RF immunity
10 V/m with 1 kHz sine-wave 80% AM from 80...2000 MHz, 10 V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz, 10 V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz, 3 V/m with 1 kHz sine-wave 80% AM from 2000...2700 MHz
Certification
North American temperature code
T4A
IEC temperature code
T4
Mechanical
Weight, approx
0.26 kg
Module location
Chassis based, any slot
