Delivery time:6-10 weeks
| Product characteristics | |
|---|---|
| Output function | normally open |
| Sensing range [mm] | 30 |
| Housing | tubular |
| Dimensions [mm] | Ø 34 / L = 82 |
| Electrical data | |
| Operating voltage [V] | 20...250 AC/DC |
| Protection class | II |
| Reverse polarity protection | no |
| Outputs | |
| Output function | normally open |
| Max. voltage drop switching output DC [V] | 6 |
| Max. voltage drop switching output AC [V] | 6.5 |
| Minimum load current [mA] | 5 |
| Max. leakage current [mA] | 2.5 (250 V AC) / 1.3 (110 V AC) / 0.8 (24 V DC) |
| Permanent current rating of switching output AC [mA] | 250; (350 (...50 °C)) |
| Permanent current rating of switching output DC [mA] | 100 |
| Short-time current rating of switching output [mA] | 2200; (20 ms / 0,5 Hz) |
| Switching frequency AC [Hz] | 25 |
| Switching frequency DC [Hz] | 50 |
| Short-circuit proof | no |
| Overload protection | no |
| Monitoring range | |
| Sensing range [mm] | 30 |
| Real sensing range Sr [mm] | 30 ± 10 % |
| Operating distance [mm] | 0...24.3 |
| Accuracy / deviations | |
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminum: 0.3 / copper: 0.2 |
| Hysteresis [% of Sr] | 1...15 |
| Switch-point drift [% of Sr] | -10...10 |
| Operating conditions | |
| Ambient temperature [°C] | -25...80 |
| Protection | IP 67 |
| Tests / approvals | |
| EMC | |
| MTTF [years] | 607 |
| Mechanical data | |
| Weight [g] | 258.3 |
| Housing | tubular |
| Mounting | non-flush mountable |
| Dimensions [mm] | Ø 34 / L = 82 |
| Material | PBT |
| Displays / operating elements | |
| Display | |
| Electrical connection | |
| Required protection | miniature fuse to IEC60127-2 sheet 1; ≤ 2 A; fast acting |
| Accessories | |
| Items supplied | |
| Remarks | |
| Remarks | |
| Pack quantity | 1 pcs. |
| Electrical connection | |
| Connection | Cable: 2 m, PVC; 2 x 0.5 mm² |
