YMX
Delivery date:6-10 weeks
| Product characteristics | |
|---|---|
| Electrical design | PNP |
| Output function | complementary |
| Sensing range [mm] | 4 |
| Housing | threaded type |
| Dimensions [mm] | M12 x 1 / L = 70 |
| Application | |
| Special feature | Gold-plated contacts |
| Electrical data | |
| Operating voltage [V] | 10...30 DC |
| Current consumption [mA] | < 10; (24 V) |
| Protection class | II |
| Reverse polarity protection | yes |
| Outputs | |
| Electrical design | PNP |
| Output function | complementary |
| Max. voltage drop switching output DC [V] | 2.5 |
| Permanent current rating of switching output DC [mA] | 200 |
| Switching frequency DC [Hz] | 1200 |
| Short-circuit protection | yes |
| Overload protection | yes |
| Detection zone | |
| Sensing range [mm] | 4 |
| Real sensing range Sr [mm] | 4 ± 10 % |
| Operating distance [mm] | 0...3.24 |
| Accuracy / deviations | |
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminium: 0.4 / copper: 0.3 |
| Hysteresis [% of Sr] | 3...15 |
| Switch point drift [% of Sr] | -10...10 |
| Operating conditions | |
| Ambient temperature [°C] | -25...80 |
| Protection | IP 67 |
| Tests / approvals | |
| EMC | |
| MTTF [years] | 1865 |
| Embedded software included | yes |
| UL approval | |
| Mechanical data | |
| Weight [g] | 30 |
| Housing | threaded type |
| Mounting | non-flush mountable |
| Dimensions [mm] | M12 x 1 / L = 70 |
| Thread designation | M12 x 1 |
| Materials | brass white bronze coated; sensing face: PBT orange; LED window: PEI; lock nuts: brass white bronze coated |
| Displays / operating elements | |
| Display | |
| Accessories | |
| Items supplied | |
| Remarks | |
| Pack quantity | 1 pcs. |
| Electrical connection - plug | |
| Connection | Connector: 1 x M12; coding: A; Contacts: gold-plated |
