Model |
ZJ10/900CZ |
|
Drilling Depth (ft) (41/2″DP) |
3300 |
|
Workover Depth (ft) (31/2″DP) |
8000 |
|
Max Hook Load (lbf) |
200000 |
|
Hook speed (ft/s) |
0.65～4.59 |
|
Mast height (ft) |
96/102 |
|
Mast type |
Mast |
|
Engine power (hp) |
350 |
|
Hydraulic transmission box |
4700 |
|
Drive ways |
Hydraulic + mechanical |
|
Traveling system |
4×3 |
|
Drilling line diameter (in) |
1” |
|
Hook block |
YG90 |
|
Swivel |
SL110 |
|
Rotary table |
ZP175 |
|
Chassis |
XD40/8×6 |
|
Approaching /Departure angle |
22°/18° |
|
Min. ground clearance (in) |
12 |
|
Max. gradient ability |
30% |
|
Min. turning diameter (ft) |
92 |
|
Overall dimension (ft) |
55×9×14 |
|
Main unit mass (lbs) |
93000 |
|
Mass of accessories (lbs) |
～33000 |
